Features and Functions of Roller Shutter Motors

Key Features

1. High Efficiency and Energy Saving

   Most modern roller shutter motors adopt DC brushless or AC silent motor technology, which boasts low power consumption and high conversion efficiency. They can operate stably for a long time without excessive energy waste, and are especially suitable for scenarios requiring frequent use.
2. Quiet and Smooth Operation

   Equipped with precision gearboxes and shock-absorbing structures, the motors run with extremely low noise (usually below 45 decibels during operation). The lifting and lowering process is smooth without jolting, effectively avoiding noise interference and mechanical wear.
3. Strong Load-Bearing Capacity

   Tailored to different types of roller shutters (such as aluminum alloy, PVC, or insulated shutters), these motors come in a variety of power ratings. The load capacity ranges from tens of kilograms to hundreds of kilograms, meeting the needs of small household windows and large industrial door openings.
4. Durable and Low-Maintenance

   The internal components are made of corrosion-resistant and high-temperature-resistant materials, which can adapt to harsh environments like humidity, dust, and extreme temperatures. With a sealed design, the motors rarely need maintenance, and their service life can reach 10–15 years under normal use.
5. Multiple Safety Protection Mechanisms

• Obstacle detection: When encountering obstacles during operation, the motor will automatically stop or reverse to prevent pinching or damage to the shutter.
• Overload protection: It will cut off power automatically if the load exceeds the rated value, avoiding motor burnout.
• Manual release: In case of power outage, a manual crank can be used to operate the shutter manually, ensuring emergency usability.

  Torque	6 N.m or 10 N.m
  Speed	17 or 28 rpm
  Power	115W
  Input Voltage	110 or 220 v
  Frequency	60HZ
  Noise index	31.2
  Motor length	573mm
  Protection grade	IP44
